Master terminal MT-07 IP
Touch screen model line with IP technology
- touch screen
- wall mounting
- call history and filtering
- complete administrator of the whole system
Communication systems nurse patient for healthcare and social care facilities
We manufacture modern communication and signaling and nurse patient communication systems that will surprise you with above-standard functions, reliability and a favorable price. They are used in health care and social services.
IP – Call communication system - full IP
The new IP model range with touch screen offers a whole new direction for hospital communication systems focussing on the future. The diverse configuration system can be used to ensure the required level of comfort.
IP - Signalling system
The signaling system based on modern IP technology offers high comfort and the possibility of easy extensibility to full-fledged communication IP devices.
The nurse-patient optical-acoustic signaling system is a cost-effective solution for patients and nursing staff in wards where voice communication is not required. It can be used mainly in hospitals in intensive care units, but also in children's or psychiatric wards thanks to its easy operation.p>
- Comfortable and clearly arranged graphic environment
- Easy operation and control on the 10.4 "touch screen
- Possibility of connection with another main terminal
- Communication takes place via LAN, using the latest VoIP technology
- Calling a participant using direct dial
- Discrete conversational connection of medical staff with patients
- Loud transmission of messages to all rooms within the department (central reporting)
- Archiving of all calls with the possibility of viewing on the terminal display
- Entering the participant's name
- Night operation (mute the speakers and all elements in the rooms at a specified time)
- Ergonomic shooting of the terminal
- Variable placement on a table or wall
- Image transmission to the main terminal from the camera, which is located at the front door
Two-way full-duplex call connection between the main terminal and the call unit at each patient bed, call room terminal or entrance call unit.
Two-way full-duplex discrete call connection for each patient bed.
GYROSCOPE IN THE HEADPHONE
Gyroscope in the handset - positional automatic switching between discrete and loud call connection (discrete call - patient holds the terminal in his hand, loud call - the terminal is hung in a holder on the wall or on the bed)
VOICE NAVIGATION IN SELECTED LANGUAGES
The voice navigation function, loud in the language of the country, transmits important location information about each active call to the entire nurses' office, which allows the medical staff to respond more quickly to the call (without having to always read the information from the main terminal display).
Auto-diagnostic functions of the system informing staff about possible non-functional parts of the system, notification of disconnected IP elements of the system and disconnected emergency call elements.
INFORMATION LCD PANEL
The information LCD panel is used to display the date, time and location of the call location, including its address identification.
PATIENT AND CLIENT SIGNALING
Wireless button WB2-F for patients
It is used for wireless activation of calls within the required area, resp. within range of the WR1 / M receiver. It allows clients to move freely around the department with the possibility of calling for help immediately.
CLIENT PASS IDENTIFICATION
WB2-G passage identification bracelet
It allows disoriented persons to move freely in the defined area with the provision of reliable protection. It is used for wireless activation of unauthorized entry or escape through a monitored passage within range of the receiver. When leaving the protected area, the information is sent to the required places, depending on the situation.
CALLING OF PERSONNEL AT RISK
Wireless button WB2-S for staff
It is used for wireless activation of calls in the required area, resp. within the deployment of WR1 / M receivers. Endangered personnel activate emergency calls with location easily and quickly. The button allows you to attach it to your hand or hang it on your neck.
